A battery of e.m.f. V volts, resistors R 1 and R 2 , a condenser C and switches S 1 and S 2 are connected in the circuit as shown in the figure below:
The condenser will get fully charged to V volts when –
Text Solution
Verified by ExpertsThe correct answer is:
D
S 1 (closed) charges the capacitor
S 2 (closed) discharges the capacitor
∴ To charge the capacitor
S 1 → closed, S 2 → opened
