The loaded 150 kg skip is rolling down the incline at 4m/s when a force P is applied to the cable as shown at time t = 0. The force P is increased uniformly with the time until it reaches 600N at t = 4s, after which time it remains constant at this value. Calculate
Text Solution
Verified by ExpertsCHECK THE SOLUTION.
Sol.
(i) The skip reverses direction when its velocity becomes zero. We will assume that this condition occurs at t = 4 + Δ t s. The impulse-momentum equation applied consistently in the positive x-direction gives
(4) (2) (600) + 2 (600) Δ t – 150(9.81) sin 30º (4 + Δ t) = 150 (0 – [–4])
46 Δ t = 1143 Δ t = 2.46s t = 4 + 2.46 = 6.46 Ans.
(ii) Applying the impulse-momentum equation to the entire interval gives
.
(4) (2) (600) + 4(2) (600) – 150(9.81) sin 30º
(8) = 150 (v – 1 [–4])
150v = 714 v = 4.76 m/s
The same result is obtained by analyzing the interval from t 1 to 8s.
