The switches in following figures are closed at t = 0 and reopened after long time at t = t 0 , then–
Text Solution
Verified by ExpertsThe correct answer is:
CHECK THE SOLUTION.
(b, c)
After long time C will be open circuit and charge on it will be CE
After long time conductor will behave as conducting wire
