An ideal fluid is flowing in two pipes of same cross-sectional pipes area. Both the pipes are connected with two vertical tubes, of length h 1 and h 2 as shown in figure. The flow is stream line in both pipes. If velocity of fluid at A, B, and C are 2 m/s, 4 m/s and 4m/s respectively, the velocity of fluid at D (in m/s) is –
Text Solution
Verified by ExpertsThe correct answer is:
CHECK THE SOLUTION.
(2)
Sol. Equation of continuity ⇒ v A + v B = v C + v D
⇒ v D = 2m/s
