Figure shows an indicator diagram. During path 1–2–3, 100 cal is given to the system and 40 cal worth work is done. During path 1 – 4 –3, the wore done is 10 cal. Then:

heat given to the system during path 1–4–3 is 70 cal

if the system is brought from 3 to 1 along straight-line path 3 –1, work done is worth 25 cal

along straight-line path 3–1 the heat ejected by the system is 85 cal

the internal energy of the system in state 3 is 140 cal above that in state

Text Solution

Verified by Experts

The correct answer is:

CHECK THE SOLUTION.

(a, b, c)

The critical step is that work in path 1-3 is mean of that for 1-2-3 and 1-4-3 (considering areas).

For 100 – 40 = x – 10 or, x = 70 cal.

It is also correct as half of (40 + 10) is 25 cal.

dU is –60, work is – 25 So, – 60 = dQ – (–25)

or, dQ = – 85 cal

hence, option is also correct.

dU = 100 – 40 = 60 cal
