Figure shows ‘P’ vs ‘T’ diagram for cyclic process ABCA undergone by ideal gas. Which of the following graph is correct (U: internal energy) –
A
B
C
D
Text Solution
Verified by ExpertsThe correct answer is:
CHECK THE SOLUTION.
(b, c)
AB: Isochoric process with increase in P and T.
BC: Isobaric process with decrease in T and V.
CA: Isothermal process with decrease in P and hence increase in V
