Six g of air is contained in the cylinder shown in Fig. The air is heated until the piston raises 50 mm. The spring just touches the piston initially. Calculate
Text Solution
Verified by ExpertsCHECK THE SOLUTION.
Sol. The pressure in the air when the piston just raises from the stops is found by balancing the forces on the piston:
PA = P atm A + W
= (100000)
+ (300) (9.81)
∴ P = 193700 Pa or 193.7 kPa
The temperature is found from the ideal-gas law:
T =
=
= 530 K
The work done by the air is considered to be composed of two parts: the raise the piston and the work to compress the spring. The work required to raise the piston a distance of 0.05 m is
W = (F) = (P) = (193.7)
(0.05) = 0.304 kJ
The work required to compress the spring is W = ½ Kx 2 = 0.5 kJ. The total work required by the air to raise the piston is
W = 0.304 + 0.5 = 0.804 kJ.
