A uniform horizontal beam of light is incident upon a prism as shown. The prism is in the shape of a quarter cylinder of radius R = 5 cm and has index of refraction μ = 1.5. A patch on the table top for a distance x from the cylinder is unilluminated. The value of x in cm is.
Text Solution
Verified by ExpertsThe correct answer is:
CHECK THE SOLUTION.
Ans. 1
Sol.
x = (y + z) – R
y = h tan θ c
z = h cot θ c
x = h[tan θ c + cot θ c] – R
sin θ c =
=
=
⇒ h =
x =
– R
= 1.71 cm
