Consider two identical galvanometers and two identical resistors with resistance R. If the internal resistance of the galvanometers R C < R/2, which of the following statement(s) about any one of the galvanometers is(are) true?

A

The maximum voltage range is obtained when all the components are connected in series

B

The maximum voltage range is obtained when the two resistors and one galvanometer are connected in series, and the second galvanometer is connected in parallel to the first galvanometer

C

The maximum current range is obtained when all the components are connected in parallel

D

The maximum current range is obtained when the two galvanometers are connected in series, and the combination is connected in parallel with both the resistors.

Text Solution

Verified by Experts

The correct answer is:

CHECK THE SOLUTION.

(b, c)

Suppose current for full deflection (i.e., For maximum range) through galvanometer is I g .

Total potential difference V 1 = 2I g (R + R C )

Total potential difference V 2 = 2I g = I g (R C + 4R)

Now since 2R C < R

So V 1 < 3I g R

while V 2 > 4RI g

So V 2 > V 1

I g R C = IR

I =

I 1 =

2I g R C = IR

I =

I 2 = I g We can be see I 1 > I 2 S
