Figure shows a circuit that contains three identical resistors with resistance R = 9.0 Ω Ω each, two identical inductors with inductance L = 2.0 mH each and an ideal battery with emf ε = 18 V. The current ‘i’ through the battery just after the switch closed is
Text Solution
Verified by ExpertsThe correct answer is:
D
equivalent circuit just after closing use switch is
= 4A
