Blocks A and B in the figure are connected by a bar of negligible weight. If A = B = 170 kg &µ A = 0.2 and µ B = 0.4, where µ A and µ B are the coefficients of limiting friction between blocks and plane, calculate the force on the bar: (g = 10 m/s 2 )
Text Solution
Verified by ExpertsThe correct answer is:
A
For → mg sin θ – T – μ Α mg cos θ = ma.…(1)
For → T + mg sin θ – μ Β mg cos θ = ma .... (2)
⇒ mg sin θ –T– μ A mg cos θ = T + mg sin θ – μ B mg cos θ
⇒ T =
( μ B – μ A )
=
(0.4–0.2) = 150N
