A 20 kg block is placed on top of 50 kg block as shown in fig. A horizontal force F acting on A causes an acceleration of 3m/s 2 to A and 2 m/s 2 to B as shown in fig. For this situation mark out the correct statement (s)
Text Solution
Verified by ExpertsThe correct answer is:
CHECK THE SOLUTION.
(a, b, c)
f = m A a = 40 N
F – f = m B a = 50 × 3 N = 150 N
F = 150 N + 40 N = 190 N
