The internal resistance of the cell shown in the figure is negligible. On closing the key K, the ammeter reading changes from 0.25 amp to amp, then –

R 1 = 10 Ω Ω

R 1 = 15 Ω Ω

Power drawn from the cell increases

The current through R decreases by 40%

Text Solution

Verified by Experts

The correct answer is:

CHECK THE SOLUTION.

(b, c)

When K was open

Reading of = amp = 0.25

∴ E = 2.5 V

When K was closed

Reading of = =

12 (5 + 0.5 R 1 ) = 10R 1

60 + 6R 1 = 10R 1

R 1 = 15 Ω Ω

Power drawn =

As R eq decreases

Power = will increases

current through R = 0.25 amp (initially)

After K is closed current through R = 0.25 amp
