In the given circuit the cells have zero internal resistance. The currents (in Amperes) passing through resistance R 1 and R 2 respectively are:
Text Solution
Verified by ExpertsThe correct answer is:
D
Assume V F = 0
V E = V F = 0
⇒ Current in R B is zero
V A – V D = 10V
⇒
from A to D
